Electric Concrete Mixer Pump

Description SMAT has been serving a large number of Foundation Free concrete batching plant customers. Hot Sale Related Cases Please check SMAT concrete pump machine case…

Share

Description

SMAT has been serving a large number of Foundation Free concrete batching plant customers.

Hot Sale

Model: JBS-30E

Max Output: 30m³/h

Power: 37KW

Power Supply: Electric Engine

Model: JBS-40E

Max Output: 40m³/h

Power: 45KW

Power Supply: Electric Engine

SMAT Concrete Pump Configuration

The parts used in SMAT concrete pumps are all top brands. Only by strictly demanding every part and link, SMAT can deliver the most satisfactory machine to customers.

Main Oil Pump Brand: Kawasaki

We adopt double pumps and double-circuit open hydraulic systems. The main pump oil circuit and S-valve swing oil circuit are independent of each other, so it is easy to determine the source of failure and eliminate it in time

01

Intermediate Relay Brand: Schneider

Fast signaling and simultaneous control of multiple circuits used to directly control motors or other electrical actuators. Work efficiently.

02

Hydraulic Hose Brand: Italy Manuli

It has an automatically enhanced lubrication system to ensure effective lubrication during the operation.

03

Seal Brand: Parker

Good elasticity and high abrasion resistance. Free with order.

04

PLC Brand: Japan Omron

Adopt modular design and easy installation. It can be customized according to engineering needs to improve the adaptability and flexibility of the equipment.In case machine parts fail, regional debugging can be used to solve the problem and avoid time costs.

05

Valves Brand: Huade or Taiwan

We adopt double pumps and double-circuit open hydraulic systems. The main pump oil circuit and S-valve swing oil circuit are independent of each other, so it is easy to determine the source of failure and eliminate it in time.

06

Engine Brand: Weichai Deutz

SMAT uses the world-famous brand engine, more stable quality, and longer service life

07

Remote

Wireless remote control operation is more safe and more convenient for operators. With the automated control system as well as intelligent operation, it can save time for training.

08

What SMAT Would Do After Confirm Oder

Our products are shipped to various sites of road construction, bridge construction, and real estate construction all over the world.

Quality Service Before Shipping

SMAT takes every order seriously. Every step of the process is checked by special person. Every important component is pre-tested before shipment, especially the mixer machine. It also ensures that free spare parts are given to the customer to avoid any possible accidents.

01

Packing and shipping

SMAT has nearly 30 years of export experience. The concrete pump manufactured by us have been exported to different countries. The Concrete Batching Plant will be packed and loaded in our factory, and then be shipped to our clients safe and sound.

02

Technical Service

SMAT provides engineers with on-site installation guidance, commissioning, and training services. SMAT engineers have rich experience in mechanical, electrical, and civil engineering. Proficiency in English and Chinese, the common languages, ensures smooth communication with operators on site.

03

Service

  • SMAT local office located in Quezon City, Manila. Make sure timely and rapid response to customer needs.
  • Filipino engineers team are always available for on-site installation guidance, commissioning, and training services.
  • SMAT provides regular visiting to clients sites, thus can promptly correct improper operations.
  • SMAT accept Peso payment.
  • Adequate stock of original spare parts to ensure the smooth operation of the project.
  • Free customized product appearance color and Logo, provide ODM support.
  • VIP groups are created for customers. If you have any questions, feel free to give feedback.
  • 7*24 hours online free consulting service, including quotation, 2-3 sets of program design, AutoCAD & 3D drawings, and site planning.

Specification

Diesel Concrete Mixer Pump for Sale

ModelJBS-30RJBS-40R
Max. theo. concrete output(L./H)30m³/h40m³/h
Mixer-rated discharge capacity0.56m³0.56m³
Max. concrete pumping pressure(H./L.)0.35m³0.45m³
Max.concrete pumping pressure(H./L.)10MPa10MPa
Distribution valve typeS ValveS Valve
Concrete cylinder diameter*strokeφ140×1000mmφ180X1000mm
Hopper capacity400L400L
Outlet diameterφ150mmφ150mm
Diesel engine modelWeichaiWeichai
Electrical engineering power66KW82KW
Rotate speed1480r/min2200r/min
Circuit typeOpen circuitOpen circuit
Pumping system pressure26MPa32MPa
Mixing system pressure6-8MPa6MPa
Capacity of oil tank260L350L
Max. Theoretical Vertical/Horizontal Conveying Distance120/300m120/500m
Max. aggregate diameterSlick/scree:10/20mmSlick/scree:40/50mm
Inside diameter of delivering pipeφ100mmφ125mm
Dimensions: length×width×height4500x1750x1600mm600x2300x3150mm
Total weight3000kg4500kg

Electric Concrete Mixer Pump for Sale

JBS-30EJBS-40E
Max. theo. concrete output(L./H)3040
Mixer rated feed capacity0.560.56
Mixer rated discharge capacity0.350.45
Max.concrete pumping pressure(H./L.)1010
Distribution valve typeS ValveS Valve
Concrete cylinder diameter*strokeΦ140X1000Φ180X1000
Hopper capacity400400
Outlet diameterΦ150Φ150
Electrical engineering power3745
Rotate speed14801480
Circuit typeOpen circuitOpen circuit
Pumping system pressure2626
Mixing system pressure6-86-8
Capacity of oil tank260370
Max. Theoretical Vertical/Horizontal Conveying Distance120/300120/500
Max. aggregate diameterSlick/scree:10/20Slick/scree:40/50
Inside diameter of delivering pipeΦ100Φ125
Dimensions: length×width×height4500x1750x16004200x2300x3150
Total weight30004500

Advantage

Tested in the Market
SMAT was established in 1988. With good credit and high quality concrete pump machine, we have won a large number of customers. Our concrete pump have been tested in the market.
01
After-Sales Service
SMAT provides engineers with on-site installation guidance, commissioning, and training services. Proficiency in English and Chinese, the common languages, ensures smooth communication with operators on site.
02
Regular Visit
We adopt double pumps and double-circuit open hydraulic systems. The main pump oil circuit and S-valve swing oil circuit are independent of each other, so it is easy to determine the source of failure and eliminate it in time.
03
Advanced Technology
We adopt double pumps and double-circuit open hydraulic systems. The main pump oil circuit and S-valve swing oil circuit are independent of each other, so it is easy to determine the source of failure and eliminate it in time.
04
Cooling System
The cooling system adopts a forced air-cooled radiator device to ensure that the working oil temperature is below 70 ℃, which ensures that the hydraulic system of the host is in normal working condition.
05
Stable Performance
Choose SMAT stable performance and high-quality concrete mixer pump, the failure rate is very low and the return rate is greatly improved. It can mix and deliver ready-mixed concrete quickly, saving time and labor costs. Ensure the proportion of concrete mixture accuracy in every batch, reducing the high cost of trial and error.
06
Intelligent Operation
Wireless remote control operation is more safe and more convenient for operators. With the automated control system as well as intelligent operation, it can save time for training.
07
Save Cost
For SMAT concrete mixer pump, less investment, higher quality concrete, which can help buyers take the investment back within a short time. Both reduce the impact on the environment and save costs.
08

Overall, the decision to choose a foundation-free concrete batching plant depends on factors such as project location, budget, schedule, and mobility requirements.
